HVAC control system design diagrams

by John I. Levenhagen

This complete "cookbook" of generic segments and sequences is a most useful reference for designers or specifiers of HVAC control systems. These highly useful control diagrams, many of them comparable to commercially available models, let you design or specify needed configurations in the most efficient manner possible. Written by an experienced HVAC control engineer, it's in full compliance with ASHRAE standards and covers both hardware and software applications. This unique volume fills a definite need and should be a part of every HVAC engineer's design library.
